Types of Lighting

There are mainly 3 types of light that are used in our homes and offices: Incandescent, Fluorescent and Light-Emitting Diode (LED).

As with most market offerings, each type of light has unique characteristics and, of course, strengths as well as weaknesses.

For a quick overview, click here to scroll down to the comparison table.

Incandescent

The most traditional type of light is the incandescent lamp. Unlike fluorescent lights that may flicker for a second or two before lighting up, incandescent bulbs light up instantly. Even though it is the least energy-efficient, it is the most common lighting used in homes. Its predominance is due to three key factors:

• Been around the longest
• Warm colour tone unique to incandescent lights
• Cheapest

There are three common types of incandescent lightbulbs:

• Standard incandescent
• Halogen
• Reflector

Standard Incandescent Lightbulb

The standard incandescent bulb (screw-in "A"-type lightbulb) is the most common of incandescent lights and also the most energy-inefficient. Its mechanics are taught in secondary school science classes - incandescent bulbs produce light from a tiny coil of tungsten wire (filament) that glows when it is heated by an electrical current. Larger wattage incandescent bulbs tend to be more efficient. Given a choice of one high wattage bulb or two lower wattage ones, it's better to go for the former. If you need only one bulb, stick to a lower wattage. Smaller wattage bulbs may have lower efficiency but will still tend to consume less power.

Halogen Lightbulb

Halogen light is another type of incandescent lighting. The bulb contains a capsule that holds gas around the filaments, making it more energy-efficient than standard incandescent bulbs. Hence these bulbs are also known as energy-saving lightbulbs. Halogen bulbs, as such, are less expensive to use but a little more expensive to buy.

Reflector Lightbulb

Reflector bulbs spread and direct light over specific areas. They are used mainly for floodlighting, spotlighting and downlighting. The two types of reflector lamps are parabolic aluminized reflector lamps (Type PAR) and ellipsoidal reflector lamps (Type ER). Ellipsoidal reflectors are twice as energy efficient as parabolic reflectors for recessed fixtures.

Fluorescent

Not only does fluorescent light last around 10 times longer than incandescent ones (take a look at the comparison table below), it uses only around 30% of the energy used by incandescent bulbs.

Fluorescent light is produced by passing an electric current through mercury and inert gases. A ballast (a device used to control the voltage in a fluorescent lamp) is required to provide a high start-up voltage and regulate the current.

CFL

CFLs combine the energy efficiency of fluorescent lighting with the convenience and popularity of incandescent fixtures. CFLs fit most fixtures designed for incandescent bulbs and use about 75% less energy. Although CFLs cost a bit more than comparable incandescent bulbs, they last 6 to 15 times as long (take a look at the comparison table below). If you switch on the light for long periods of time, switching from incandescent to CFL will save you a pretty penny in the long run.

The PLC (Philips Linear - Compact) light is a common type of CFL light. The key feature of PLCs, as opposed to other CFLs, is that the ballast is part of the light fixture and not part of the bulb. PLC lamps tend to be cheaper as a result.

Fluorescent Tube & Circline Bulb

Fluorescent tube is another popular lighting used in Singapore. Traditional tube-type fluorescent lights are usually identified as T12 or T8 (12/8 or 8/8 of an inch tube diameter, respectively). 40-watt, 4-foot (1.2-meter) lamps, and 75-watt, 8-foot (2.4-meter) lamps are two of the most common types. They are installed in dedicated fixtures with built-in ballasts.

Circular and tubular fluorescent fixtures are often used for ambient lighting in large indoor areas as their low brightness creates less direct glare than incandescent bulbs.

Fluorescent lights are not without weaknesses. CFLs take a few moments to reach full brightness. Also, if a fluorescent lamp is broken, the mercury contained will escape. According to the National Environment Agency (NEA), the trace amounts of mercury released is unlikely to pose a threat to human health. All the same, NEA advises minimizing exposure and avoiding direct contact with broken fluorescent lamps.

LED

The newest type of light to hit the residential lighting market is the light-emitting diode (LED). It is one of the most energy-efficient lighting available for use today.

An LED light consists of small dots emitting a mix of red, green and blue to form white light. Unlike incandescent bulbs and CFLs, LEDs emit very little heat and also minimise the need for reflectors and diffusers. This make LEDs much more efficient. Furthermore, LED light bulbs are hardier and last longer than other types of residential lighting. As LEDs have such long lifespans, which equates to having to change the light less often, they are ideal for hard-to-reach areas.

Due to LED's advantages, it's no surprise that it cost significantly more than other lighting options. Beside the higher price tag, LED lights, as of February 2013, still cannot produce the warm atmospheric tones that incandescent and fluoroscent lights can.

Update May 2016: Prices of LED lights have plummeted. You can now get an LED bulb for less than $5. As if that is not enough, LED technology has recently advanced to deliver warms colour tones as good as incandescent bulbs! With economical and energy-efficient lights like LEDs and CFLs, it's no wonder that incandescent light bulbs are being phased out in countries such as USA, China and even our neighbour, Malaysia.

Comparison of Lightings

Lighting Type	Energy Efficiency (on a scale of 1 to 10)	Lifetime (hours)	Color Tone
Standard incandescent bulb	0.9 — 1.5	750 — 2,500	Warm
Halogen bulb	1.1 — 2.0	1,000 — 4,000	Warm to Neutral
Reflector bulb	1.1 — 1.7	2,000 — 3,000	Warm
Compact fluorescent lamp (CFL)	4.5 — 6.4	10,000	Warm to Cold
Fluorescent tube	2.7 — 10	7,000 — 24,000	Warm to Cold
Fluorescent circuline bulb	3.6 — 4.5	12,000	Warm to Cold
Cool white LED	5.5 — 8.4	20,000 — 50,000	Cold
Warm white LED	2.5 — 4.9	20,000 — 50,000	Neutral to Warm
